Cloudflare Workers AI: Production-Ready Guide for Real Applications

Cloudflare Workers AI: Production-Ready Guide

Cloudflare Workers AI delivers serverless GPU inference at the edge, enabling you to add AI capabilities—embeddings, content moderation, smart suggestions—without managing infrastructure. This guide goes beyond basic docs to cover real architectural patterns, cost optimization, and production gotchas.

What You'll Learn

• Setting up Workers AI with modern wrangler.jsonc configuration
• Building a RAG pipeline with Vectorize for semantic search
• Content moderation with Llama Guard
• Function calling for intelligent agents
• Structured JSON outputs for API responses
• Cost optimization strategies that actually work
• Async processing with Queues
• Chatbot with conversation history
• Common gotchas and debugging tips

Prerequisites

• A Cloudflare account
• Node.js 18+ and pnpm/npm
• Basic TypeScript knowledge
• Familiarity with REST APIs

Setting Up Your Workers AI Project

Modern Workers projects use wrangler.jsonc (JSON with comments)—Cloudflare now recommends this over TOML for new projects:

{
  "$schema": "./node_modules/wrangler/config-schema.json",
  "name": "my-ai-app",
  "main": "src/index.ts",
  "compatibility_date": "2024-12-01",

  "ai": { "binding": "AI" },

  "vectorize": [{
    "binding": "TASK_INDEX",
    "index_name": "tasks-vector-index"
  }],

  "d1_databases": [{
    "binding": "DB",
    "database_name": "myapp",
    "database_id": "<YOUR_DATABASE_ID>",
    "migrations_dir": "migrations"
  }],

  "kv_namespaces": [{
    "binding": "CACHE",
    "id": "<YOUR_KV_ID>",
    "preview_id": "<YOUR_PREVIEW_KV_ID>"
  }],

  "queues": {
    "producers": [{ "binding": "EMBEDDING_QUEUE", "queue": "embedding-jobs" }],
    "consumers": [{ "queue": "embedding-jobs", "max_batch_size": 10, "max_batch_timeout": 5 }]
  },

  "observability": { "enabled": true, "head_sampling_rate": 0.1 }
}

TypeScript interface for your environment bindings:

export interface Env {
  AI: Ai;
  TASK_INDEX: Vectorize;
  DB: D1Database;
  CACHE: KVNamespace;
  EMBEDDING_QUEUE: Queue;
  API_KEY: string;
}

Important: Never put secrets in your config file. Use npx wrangler secret put API_KEY and store local development secrets in .dev.vars (add to .gitignore).

Choosing the Right Model

Workers AI offers 50+ models. Here's a strategic breakdown:

Cost per million tokens:

The free tier gives you 10,000 Neurons/day—approximately 1,300 small-model LLM responses or 10,000+ embeddings.

Building a RAG Pipeline for Semantic Search

This pattern enables semantic search—users can find items even when using different words:

import { Hono } from "hono";

const app = new Hono<{ Bindings: Env }>();

// Ingest a new item into the vector database
app.post("/items", async (c) => {
  const { id, title, description, tags } = await c.req.json();

  // Combine relevant fields for embedding
  const textToEmbed = `${title}. ${description}. Tags: ${tags.join(", ")}`;

  // Generate embedding
  const embedding = await c.env.AI.run("@cf/baai/bge-base-en-v1.5", {
    text: textToEmbed,
  });

  // Store in D1
  await c.env.DB.prepare(
    "INSERT INTO items (id, title, description, tags, created_at) VALUES (?, ?, ?, ?, ?)"
  ).bind(id, title, description, JSON.stringify(tags), Date.now()).run();

  // Upsert to Vectorize with metadata for filtering
  await c.env.TASK_INDEX.upsert([{
    id: id,
    values: embedding.data[0],
    metadata: {
      tags: tags.join(","),
      created_at: Date.now(),
    },
  }]);

  return c.json({ success: true, id });
});

// Semantic search
app.get("/search", async (c) => {
  const query = c.req.query("q") || "";
  const limit = parseInt(c.req.query("limit") || "10");

  // Generate query embedding
  const queryEmbedding = await c.env.AI.run("@cf/baai/bge-base-en-v1.5", {
    text: query,
  });

  // Search Vectorize
  const results = await c.env.TASK_INDEX.query(queryEmbedding.data[0], {
    topK: limit,
    returnMetadata: "all",
  });

  if (results.matches.length === 0) {
    return c.json({ items: [], query });
  }

  // Fetch full details from D1
  const ids = results.matches.map(m => m.id);
  const placeholders = ids.map(() => "?").join(",");
  const { results: items } = await c.env.DB.prepare(
    `SELECT * FROM items WHERE id IN (${placeholders})`
  ).bind(...ids).all();

  // Sort by similarity score
  const rankedItems = results.matches.map(match => ({
    ...items.find(item => item.id === match.id),
    similarity: match.score,
  }));

  return c.json({ items: rankedItems, query });
});

export default app;

Create your Vectorize index:

npx wrangler vectorize create tasks-vector-index --dimensions=768 --metric=cosine

Content Moderation with Llama Guard

Llama Guard 3 8B classifies content across 14 hazard categories (violence, hate speech, sexual content, etc.):

interface ModerationResult {
  safe: boolean;
  categories?: string[];
}

async function moderateContent(
  env: Env,
  userContent: string,
  aiResponse?: string
): Promise<ModerationResult> {
  const messages = [
    { role: "user" as const, content: userContent },
    ...(aiResponse ? [{ role: "assistant" as const, content: aiResponse }] : []),
  ];

  const response = await env.AI.run("@cf/meta/llama-guard-3-8b", { messages });

  const responseText = response.response as string;
  const isSafe = responseText.toLowerCase().includes("safe");

  // Extract categories if flagged (format: "unsafe\nS1, S7")
  let categories: string[] = [];
  if (!isSafe && responseText.includes("\n")) {
    categories = responseText.split("\n")[1]?.split(",").map(s => s.trim()) || [];
  }

  return { safe: isSafe, categories };
}

// Moderation middleware
app.post("/content/submit", async (c) => {
  const { content } = await c.req.json();

  const moderation = await moderateContent(c.env, content);

  if (!moderation.safe) {
    return c.json({
      error: "Content flagged for review",
      categories: moderation.categories,
    }, 400);
  }

  // Proceed with content processing...
});

Hazard categories: S1: Violent Crimes, S2: Non-Violent Crimes, S3: Sex-Related Crimes, S4: Child Exploitation, S5: Defamation, S6: Specialized Advice, S7: Privacy, S8: Intellectual Property, S9: Weapons, S10: Hate Speech, S11: Self-Harm, S12: Sexual Content, S13: Elections, S14: Code Abuse

Streaming Responses

For features like autocomplete or typing indicators:

app.post("/suggestions/stream", async (c) => {
  const { prompt } = await c.req.json();

  const stream = await c.env.AI.run("@cf/meta/llama-3.2-3b-instruct", {
    messages: [
      { role: "system", content: "You're a helpful assistant. Be concise." },
      { role: "user", content: prompt },
    ],
    stream: true,
    max_tokens: 256,
  });

  return new Response(stream as ReadableStream, {
    headers: {
      "Content-Type": "text/event-stream",
      "Cache-Control": "no-cache",
      "Connection": "keep-alive",
    },
  });
});

Function Calling for Intelligent Agents

Workers AI supports embedded function calling via @cloudflare/ai-utils:

import { runWithTools } from "@cloudflare/ai-utils";

app.post("/agent", async (c) => {
  const { userMessage, userId } = await c.req.json();

  const response = await runWithTools(
    c.env.AI,
    "@hf/nousresearch/hermes-2-pro-mistral-7b",
    {
      messages: [
        { role: "system", content: "You're a helpful assistant. Use tools when needed." },
        { role: "user", content: userMessage },
      ],
      tools: [
        {
          name: "searchItems",
          description: "Search for items matching a query",
          parameters: {
            type: "object",
            properties: {
              query: { type: "string", description: "Search query" },
            },
            required: ["query"],
          },
          function: async ({ query }) => {
            const embedding = await c.env.AI.run("@cf/baai/bge-base-en-v1.5", { text: query });
            const results = await c.env.TASK_INDEX.query(embedding.data[0], { topK: 5 });
            return JSON.stringify(results.matches);
          },
        },
        {
          name: "getUserProfile",
          description: "Get the current user's profile",
          parameters: { type: "object", properties: {} },
          function: async () => {
            const user = await c.env.DB.prepare(
              "SELECT * FROM users WHERE id = ?"
            ).bind(userId).first();
            return JSON.stringify(user);
          },
        },
      ],
    }
  );

  return c.json(response);
});

Structured JSON Outputs

When you need guaranteed JSON schema compliance:

app.post("/analyze", async (c) => {
  const { text } = await c.req.json();

  const response = await c.env.AI.run("@cf/meta/llama-3.1-8b-instruct", {
    messages: [
      { role: "system", content: "Analyze the text and categorize it." },
      { role: "user", content: text },
    ],
    response_format: {
      type: "json_schema",
      json_schema: {
        type: "object",
        properties: {
          category: {
            type: "string",
            enum: ["tech", "business", "lifestyle", "other"],
          },
          sentiment: {
            type: "string",
            enum: ["positive", "neutral", "negative"],
          },
          keywords: {
            type: "array",
            items: { type: "string" },
          },
        },
        required: ["category", "sentiment", "keywords"],
      },
    },
  });

  // Response is guaranteed to match schema
  const parsed = JSON.parse(response.response as string);
  return c.json(parsed);
});

Note: JSON mode does not support streaming. The stream: true parameter is ignored when using response_format.

Cost Optimization Strategies

1. Aggressive Caching with AI Gateway

const response = await env.AI.run(
  "@cf/meta/llama-3.2-3b-instruct",
  { messages: [...] },
  {
    gateway: {
      id: "my-gateway",
      skipCache: false,
      cacheTtl: 3600,
    },
  }
);

AI Gateway caching can reduce 90% of redundant inference costs.

2. Semantic Caching with KV

async function getCachedOrGenerate(
  env: Env,
  prompt: string,
  model: string
): Promise<string> {
  const encoder = new TextEncoder();
  const data = encoder.encode(prompt);
  const hashBuffer = await crypto.subtle.digest("SHA-256", data);
  const hashArray = Array.from(new Uint8Array(hashBuffer));
  const cacheKey = `ai:${model}:${hashArray.map(b => b.toString(16).padStart(2, "0")).join("")}`;

  const cached = await env.CACHE.get(cacheKey);
  if (cached) return cached;

  const result = await env.AI.run(model as any, {
    messages: [{ role: "user", content: prompt }],
  });

  await env.CACHE.put(cacheKey, result.response as string, {
    expirationTtl: 86400,
  });

  return result.response as string;
}

3. Model Routing by Complexity

function selectModel(taskType: string, inputLength: number): string {
  if (taskType === "classification" || inputLength < 100) {
    return "@cf/meta/llama-3.2-1b-instruct"; // Cheapest
  }
  if (taskType === "suggestions") {
    return "@cf/meta/llama-3.2-3b-instruct"; // Good balance
  }
  if (taskType === "complex_reasoning") {
    return "@cf/meta/llama-3.3-70b-instruct-fp8-fast"; // Best quality
  }
  return "@cf/meta/llama-3.1-8b-instruct-awq"; // Default
}

Async Processing with Queues

For operations that shouldn't block your API:

// Producer: Queue jobs when items are created
app.post("/items", async (c) => {
  const item = await c.req.json();

  // Save to D1 immediately
  await c.env.DB.prepare(
    "INSERT INTO items (id, title, description, status) VALUES (?, ?, ?, ?)"
  ).bind(item.id, item.title, item.description, "pending_embedding").run();

  // Queue background embedding
  await c.env.EMBEDDING_QUEUE.send({
    itemId: item.id,
    text: `${item.title}. ${item.description}`,
  });

  return c.json({ itemId: item.id, status: "processing" });
});

// Consumer: Process embedding queue
export default {
  async queue(batch: MessageBatch<{ itemId: string; text: string }>, env: Env) {
    for (const message of batch.messages) {
      try {
        const { itemId, text } = message.body;

        const embedding = await env.AI.run("@cf/baai/bge-base-en-v1.5", {
          text: text,
        });

        await env.TASK_INDEX.upsert([{
          id: itemId,
          values: embedding.data[0],
        }]);

        await env.DB.prepare(
          "UPDATE items SET status = ? WHERE id = ?"
        ).bind("active", itemId).run();

        message.ack();
      } catch (error) {
        console.error(`Failed: ${message.body.itemId}`, error);
        message.retry();
      }
    }
  },

  async fetch(request: Request, env: Env) {
    return app.fetch(request, env);
  },
};

Chatbot with Conversation History

interface Message {
  role: "user" | "assistant" | "system";
  content: string;
}

app.post("/chat", async (c) => {
  const { sessionId, message } = await c.req.json();
  const historyKey = `chat:${sessionId}`;

  const stored = await c.env.CACHE.get(historyKey, "json") as Message[] | null;
  const messages: Message[] = stored || [
    { role: "system", content: "You're a helpful assistant. Be concise." },
  ];

  messages.push({ role: "user", content: message });

  // Sliding window to prevent context overflow
  const contextMessages = [
    messages[0],
    ...messages.slice(-20),
  ];

  const response = await c.env.AI.run("@cf/meta/llama-3.1-8b-instruct", {
    messages: contextMessages,
    max_tokens: 512,
  });

  messages.push({ role: "assistant", content: response.response as string });

  await c.env.CACHE.put(historyKey, JSON.stringify(messages), {
    expirationTtl: 3600,
  });

  return c.json({ response: response.response });
});

Common Gotchas

1. Memory Limits (128MB on Workers)

// ❌ Problem: Loading large files into memory
const largeFile = await response.arrayBuffer(); // Can OOM

// ✅ Solution: Stream processing
const { readable, writable } = new TransformStream();
response.body.pipeTo(writable);
return new Response(readable);

2. CPU Time Limits (50ms paid, 10ms free)

// ❌ Avoid: Pure-JS crypto (slow)
import CryptoJS from "crypto-js";
const hash = CryptoJS.SHA256(data);

// ✅ Use: WebCrypto API (native, instant)
const hash = await crypto.subtle.digest("SHA-256", data);

3. Development Costs

⚠️ CRITICAL: Running `wrangler dev` with Workers AI bindings
   still connects to Cloudflare's remote GPU infrastructure.
   You WILL be charged for AI usage during local development.

4. Error Handling with Retry

async function runWithRetry<T>(
  fn: () => Promise<T>,
  maxRetries: number = 3
): Promise<T> {
  let lastError: Error | null = null;

  for (let attempt = 0; attempt < maxRetries; attempt++) {
    try {
      return await fn();
    } catch (error: any) {
      lastError= error;

      if (error.message?.includes("400") || error.message?.includes("401")) {
        throw error; // Don't retry client errors
      }

      if (error.message?.includes("Capacity") || error.message?.includes("timeout")) {
        await new Promise(r=> setTimeout(r, Math.pow(2, attempt) * 1000));
        continue;
      }

      throw error;
    }
  }

  throw lastError;
}

Essential CLI Commands

# Development
wrangler dev                          # Start local dev server
wrangler dev --remote                 # Use remote resources

# Deployment
wrangler deploy                       # Deploy to production
wrangler deploy --env staging         # Deploy to staging

# Database
wrangler d1 create myapp              # Create D1 database
wrangler d1 execute myapp --local --file=schema.sql
wrangler d1 execute myapp --remote --file=schema.sql

# Vector Index
wrangler vectorize create my-index --dimensions=768 --metric=cosine

# KV
wrangler kv namespace create CACHE

# Secrets
wrangler secret put API_KEY

# Logs
wrangler tail                         # Stream production logs
wrangler tail --search "error"        # Filter logs

Conclusion

Cloudflare Workers AI provides a powerful platform for adding AI to your applications with minimal operational overhead. The key patterns are:

• Semantic search using BGE embeddings + Vectorize
• Content moderation with Llama Guard
• Smart suggestions using small models (1B-3B) for speed and cost
• Async processing via Queues for embedding generation
• Aggressive caching through AI Gateway and KV

The free tier's 10,000 daily Neurons is sufficient for prototyping, with paid usage scaling predictably at $0.011 per 1,000 Neurons.

Related Resources

• Cloudflare Workers AI Documentation
• Workers AI Models Catalog
• Vectorize Documentation
• D1 Database Documentation
• Cloudflare Queues
